This XS Max came in for static/weird sounds during phone calls.
The audio will work fine with music app & youtube.
Split the sandwich & found 6 critical pads ripped.
The phone was smashed, so not surprising it was a sandwich issue.
After fixing all the pads, resandwiching, it's now fixed 🤩
This reminds me a lot like my post a few days ago. But this time, it wasn't the rear mic, but a board issue.
Have you seen this issue before? 👀
If you have a Seek Thermal Cam, you're missing out if you don't have a VCC Seek Stand: https://www.vccboardrepairs.com/buy-seek-stand
Injured Gadgets just got these back in stock, so get them while you can!
It can take us a while to build these out sometimes, so they're sometimes out of stock for a while, but we're working towards always having inventory ready to build more as they sell out.
This stand makes using a thermal cam so easy. So much better than any other thermal solution on the market.
It allows you to get real close up (using my Macro Lens), and easily find where the short is coming from.
Plus it's hard free, so you can have your hands free to try to boot the device from DCPS, while having an image that is in focus & not moving around.
You can even record a video through the app, while you inject voltage into the short, so you can go back & see exactly which component was it that was heating up.
Save yourself lots of time by getting a Seek Cam, Stand & Macro Lens! ...
Anyone who is doing game console repairs, knows how many screws you need to remove to access the motherboard.
Especially the PS5, with the 5,000 screws or so.
If you don't already have an electric screwdriver, GET ONE ASAP.
🌟 Cordless Screwdriver with T9 Bit: https://amzn.to/3E5duCj
🌟Extended T9 Bit: https://amzn.to/3c4YJac
It's rechargeable through micro USB and allows you to easily swap the tips out. You can also fold it to be straight or L shape.
Let me know below if you are already using an electric screwdriver 👇👇
In case you haven't heard, I will be moving from Las Vegas, NV to Star, ID.
In my Las Vegas office, I had fully custom built workbenches for myself & my employee(s). But now it's time to go & tear everything down.
I'm really sad since these benches felt like the perfect layout! Or maybe I just got used to them.
I've attached some pics of what it looked like before & now that's all gone.
I do have some good news tho.... I recorded a detailed video of my office for youtube! I'll be posting that video soon!
Like this post if you want to see that video!
Hey guys! I'm so glad to finally get here. Thank you Jesse for the encouragement. Took me a minute but I'm here. I'm so eager to learn and grow. I have some experience with soldering etc, I can treat with obvious issues but there's something about diagnosing issues (especially with iPhones) that I have trouble with. I'm hoping this community can help with that.
Currently I have two iPhone 13 devices that need repair. One is stuck in recovery mode. A flash was attempted but there was an error during the process (Error 4013).
The other 13 does not boot or charge. It pulls 0.02A on the ammeter and I can feel both the back getting really hot. I tried this with two batteries. I also noticed that the wireless charging IC also gets very hot (338S00817) even when using a wired charger.
Remember I'm a noob so please....be gentle. Any help greatly appreciated. Thanks in advance!
A funny example of why board repair are still very human skills.
Someone posted in my Facebook group asking for help identifying a ripped pad on a PS5 fan connector. The connector had been torn off the board, and they wanted to know what signal the missing middle pad belonged to so they could run a jumper.
A commenter decided to let AI handle it.
They fed the photo into ChatGPT and got back a nice-looking annotated diagram showing all the pin functions. The problem?
It was completely wrong.
The AI labeled the missing pad as the TACH signal when in reality that pad is ground.
The scary part is that if you didn't already know the answer, the diagram looks convincing. It has arrows, labels, colors, callouts, and all the confidence in the world. Yet it still gave bad information that could send someone down the wrong path.
This is one of the reasons I don't lose sleep over AI replacing board repair technicians.
AI is incredibly good at summarizing information that already exists publicly. But in...
